| Bhiwandi, Thane, Maharashtra |
 |
|
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler, Trader |
| Material | Mild Steel, Stainless Steel |
| Surface | Polished |
| Application | Industrial |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
""All radius & dimensions mentioned above are standard, any other radius or customer drawings can also be made as per order"
CCMT Type
| Product Name | Dimensions(mm) | |||
| ISO Name | A | d | t | R |
| CCMT-060202 | 3.5 | 6.35 | 2.38 | 0.2 |
| CCMT-060204 | 3.4 | 6.35 | 2.38 | 0.4 |
| CCMT-09T302 | 3.8 | 9.52 | 3.97 | 0.2 |
| CCMT-09T304 | 3.6 | 9.52 | 3.97 | 0.4 |
| CCMT-09T308 | 3.4 | 9.52 | 3.97 | 0.8 |
| CCMT-120404 | 3.6 | 12.7 | 4.76 | 0.4 |
| CCMT-120408 | 3.4 | 12.7 | 4.76 | 0.8 |
CNMA Type
| Product Name | Dimensions(mm) | ||
| ISO Name | A | d | t |
| CNMA-120402 | 3.8 | 12.7 | 4.76 |
| CNMA-120404 | 3.6 | 12.7 | 4.76 |
| CNMA-120408 | 3.4 | 12.7 | 4.76 |
